AspectRatio

The AspectRatio component ensures that its children maintain a specific width-to-height ratio, making it ideal for videos, images, or placeholders that need to be consistently sized across devices.

Preview

Preview

Code

import { AspectRatio } from '@ignix-ui/aspectratio';

function MyComponent() {
  return (
    <AspectRatio ratio="16:9" maxWidth="400px">
      <img src="https://thumbs.wbm.im/pw/medium/859204cf5b71808ed4c6bd19d95974c6.jpg" alt="Demo Image" />
    </AspectRatio>
  );
}

Installation

CLI

ignix add component aspectratio

manual

import { cn } from '../../../utils/cn';
import * as React from 'react';

export interface AspectRatioProps extends React.HTMLAttributes<HTMLDivElement> {
ratio?: '1:1' | '4:3' | '16:9' | '21:9' | string;
/**
* The maximum width of the container.
* - Accepts a string (e.g., '50%', '30rem', '400px')
* - Or a number (auto-converted to 'px')
*/
maxWidth?: string | number;
children: React.ReactNode;
}

const parseRatio = (ratio: string) => {
const [w, h] = ratio.split(':').map(Number);
return w && h ? { w, h } : { w: 1, h: 1 };
};

const AspectRatio = React.forwardRef<HTMLDivElement, AspectRatioProps>(
({ ratio = '1:1', maxWidth, children, className, style, ...props }, ref) => {
const { w, h } = parseRatio(ratio);

const isAspectRatioSupported =
  typeof CSS !== 'undefined' && CSS.supports('aspect-ratio', '1/1');

const computedWidth =
  typeof maxWidth === 'number' ? `${maxWidth}px` : (maxWidth ?? '100%');

const containerStyle: React.CSSProperties = {
  position: 'relative',
  width: computedWidth,
  maxWidth: '100%',
  aspectRatio: `${w} / ${h}`,
  ...style,
};

if (isAspectRatioSupported) {
  containerStyle.aspectRatio = `${w} / ${h}`;
} else {
  containerStyle.position = 'relative';
  containerStyle.paddingBottom = `${(h / w) * 100}%`;
}

const contentStyle: React.CSSProperties = isAspectRatioSupported
  ? { width: '100%', height: '100%' }
  : {
      position: 'absolute',
      top: 0,
      left: 0,
      width: '100%',
      height: '100%',
    };

const enhancedChildren = React.Children.map(children, (child) => {
  if (
    React.isValidElement(child) &&
    typeof child.type === 'string' &&
    child.type === 'img'
  ) {
    const imgElement = child as React.ReactElement<
      React.ImgHTMLAttributes<HTMLImageElement>
    >;

    return React.cloneElement(imgElement, {
      className: cn(
        imgElement.props.className,
        'object-cover w-full h-full'
      ),
    });
  }
  return child;
});

return (
  <div
    ref={ref}
    className={cn('aspect-ratio-container', className)}
    style={containerStyle}
    {...props}
  >
  {isAspectRatioSupported ? (
    enhancedChildren
  ) : (
    <div style={contentStyle}>{enhancedChildren}</div>
  )}
  </div>
);
}
);

AspectRatio.displayName = 'AspectRatio';

export { AspectRatio };

Usage

Import the component:

import { AspectRatio } from '@ignix-ui/aspectratio';

Basic Usage

function BasicAspectRatio() {
  return (
    <AspectRatio ratio="4:3" maxWidth="500px">
      <img src="https://thumbs.wbm.im/pw/medium/859204cf5b71808ed4c6bd19d95974c6.jpg" alt="Demo Image" />
    </AspectRatio>
  );
}

Props

Prop	Type	Default	Description
ratio	"1:1" | "4:3" | "16:9" | "21:9" | string	"1:1"	The width-to-height ratio. Accepts any custom "W:H" string
maxWidth	string | number	-	Maximum width of the container. (e.g. "50%", "30rem", "400px"). Numbers are auto-converted to px
children	React.ReactNode	required	Content rendered inside the ratio container. Direct <img> children automatically receive object-cover w-full h-full
